120VAC To 24VDC Dimmable Led Transformer
24V 2A LED driver is power enough,good stability,factory directly sale,large quantity discount,support customization.
- Product Introduction
Introduction
Are you still troubled by inferior products? Our 120VAC To 24VDC Dimmable Led Transformer has sufficient power, safety, and stability, and has all-around protection functions. It is a very safe transformer. It is widely used in industrial automation, LED lighting, communications, transportation, home appliances, electronic instruments, and other fields. At the same time, we use high-quality components instead of inferior second-hand components, so the product quality is stable and the service life is long. Sufficient power and a high conversion rate not only make it more durable but also more energy-saving and environmentally friendly. In addition, our products will be tested before leaving the factory, so the quality is very reliable.
Features
1. 120VAC To 24VDC Dimmable Led Transformer uses a hollowed-out metal case, so the heat dissipation effect is greatly enhanced.
2. Short circuit protection, over-temperature protection, overload protection, and other functions can ensure the safety of the circuit and protect your safety.
3. Imported IC, pure copper transformer and magnetic ring, and long-life capacitors make the product more efficient and durable.
4. The intelligent management chip can reduce the loss and make the power supply run more stably.
Details
property | Model |
P-50W-24V | |
Output voltage | 24V±5% |
Output Current | 2A |
Ripple and noise | 100mVp-p |
Output power | 50W |
Efficiency | 86% |
Input voltage | 90-264VAC |
Input frequency | 47-63Hz |
Input current | 1A/110V 0.5A/220V |
Cold start current | 0.7A/170V 0.3A/260V |
Leakage current | <0.5mA/260VAC |
Waterproof grade | IP20 |
Overload protection | 105%-110%,cut off the output,reset:automatic recovery |
Short circuit protection. | Have |
Over voltage protection | Have |
Temp coefficient | ±0.03%℃(0-5℃) |
Start,rise,hold time | 200ms,50ms,20ms |
Shoct resistance | 10-500Hz,2G 10min,/1 cycle，60 minutes，each axis |
Pressure | I/P-O/P:1.5KVAC,I/P-FG 1.5KVAC,O/P-FG:0.5KVAC |
Runing Temp,humidity | -20℃~+60℃，20%~90%RH |
Storage Temp，humidity | -30℃~+85℃，10%~95%RH |
Dimension | 110*78*35mm |
Weight | 0.28Kg |
Security Standard | CE FCC ROHS |
FAQ:
Q1:Can I get a sample for testing?
A1: Sure, but sample fees should be charged on your account.
Q2: What's the mormal lead time?
A2: 3-5 working days for samples, 15-20 working days for mass production.
If you have any problems,please don’t hesitate to call or email us immediately for more info.
Why choose us?
- We understand the importance of compliance with safety regulations and ensure that all our products meet or exceed safety standards.
- Our company has established a certain scale and has a solid foundation and excellent supporting capabilities. It has become the research and development, production, and sales base of 120VAC To 24VDC Dimmable Led Transformer. Our products have a high penetration rate and have benefited many regions and countries.
- Our products and services are designed to meet the needs of customers across various industries and sectors.
- You can contact us to tell us your ideas, we can customize the right products for you according to your needs.
- We understand the importance of timely delivery and work to ensure your products arrive on time and in perfect condition.
- Our company is engaged in technological innovation, which can be said to be eight immortals crossing the sea.
- We have invested heavily in technology and equipment to ensure the highest levels of quality and reliability in our products.
- The development of our company is not without the support and love of our customers, we want to sincerely thank each and every one of our customers!
- As a supplier and manufacturer, we strive to offer competitive pricing for our products.
- Our market concept is that the enterprise's reputation is the invisible market, and the user's satisfaction is the eternal market.
