Power Supply 24V 1200W
power supply 1200w power supply 24v power supply 24v 50a power supply 24v 1200w
- Product Introduction
|
Model |
|
|
P-1200W-24V |
|
|
Output voltage |
24V±6% |
|
Output Current |
50A |
|
Ripple and noise |
180mVp-p |
|
Output power |
1200W |
|
Efficiency |
87% |
|
Input voltage |
90-264VAC |
|
Input frequency |
47-63Hz |
|
Input current |
26A/110V 13A/220V |
|
Cold start current |
80A/170V 72A/260V |
|
Leakage current |
<0.5mA/260VAC |
|
Waterproof grade |
IP20 |
|
Overload protection |
105%-110%,cut off the output,reset:automatic recovery |
|
Short circuit protection. |
Have |
|
Over voltage protection |
Have |
|
Temp coefficient |
±0.03%℃(0-5℃) |
|
Start,rise,hold time |
200ms,50ms,20ms |
|
Shoct resistance |
10-500Hz,2G 10min,/1 cycle,60 minutes,each axis |
|
Pressure |
I/P-O/P:1.5KVAC,I/P-FG 1.5KVAC,O/P-FG:0.5KVAC |
|
Runing Temp,humidity |
-20℃~+60℃,20%~90%RH |
|
Storage Temp,humidity |
-30℃~+85℃,10%~95%RH |
|
Dimension |
240*125*65mm |
|
Weight |
1.45Kg |
|
Security Standard |
CE FCC ROHS |
Switching power supply 24v 1200w is a high-performance and high-efficiency industrial power supply equipment. It adopts advanced technology and high-quality materials to ensure its reliability and stability, providing users with a sturdy, durable, efficient and energy-saving power solution.
This device has multiple protective measures, such as overcurrent, overvoltage, short circuit, etc., which can prevent voltage instability or excessive current from causing damage to electrical equipment, ensuring the safety and reliability of user equipment.
At the same time, the 24V 50A switching power supply also has the characteristic of high efficiency, which can convert the power supply into high-quality electrical energy output, maximizing energy savings and reducing operating costs. This power supply device has a wide range of application scenarios, such as industrial automation equipment, LED lighting equipment, communication equipment, medical equipment, and other fields.
In summary, the 24V 50A 1200W switch mode power supply is a high-quality and high-performance power supply device with multiple excellent features and functions, providing users with strong power protection and helping them easily achieve efficient, safe, and stable operation. It is one of the indispensable and important equipment for the development of modern industries, and also an important component for achieving sustainable development in the future.
We are always waiting for your contact.Please kindly leave your email or telephone.Then you will be touched soon.
